REHAU 70/80 / PVC window

Back to PVC window

Rehau 70/80

PVC windows and doors system made with a “Rehau” profile with a double gasket with 5 chambers. Sash can be with a round or straight profile.

FINISHES

The profiles can be mass-coloured or coated (film-coated); the surface coating of the profiles is obtained by hot gluing acrylic and laminated films structured to be resistant to light and abrasions. These films can be in RAL colour and wood decoration.

DIMENSIONS

Fixed window frame 70 x 68 mm section.
Mobile Sash straight profile 70 x 80 mm section.
Mobile Sash round profile 78 x 80 mm section.

HARDWARE

Standard Roto NT hardware with tilt and turn and lever rod. Complete with anti-burglary striker plates and pawls along the entire perimeter.

GASKET AND SEAL

Double abutment sealing profile, double gasket; glazing bead with a choice of two shapes: rounded or squared; drainage through holes in the lower crosspiece and external holes covered by caps, threshold with thermal break in anodised aluminium and polyamide on French windows.

DOUBLE-GLAZING

Use of low-emission single-chamber double glazing with Argon gas and warm edge ducts as standard, in accordance with the current regulations. Of variable thicknesses and types (solar control, safety, acoustic, satin …) according to requirements.

THERMAL TRANSMITTANCE*

Thermal insulation achievable up to UW value of 1.06 W/m2K.

*Calculated thermal values (according to the standard UNI EN ISO 10077-1 and 2), with Uf = 1.3 (W/m²K), low-emission double glazing with warm-edge duct (warm edge) and Ug value = 1.1 (W/m²K) best thermal insulation value referring to the double glazing with best thermal transmittance present in the price list and warm-edge duct (warm edge).

ACOUSTIC PROTECTION

Starting from 31 dB for windows based on glass noise reduction values up to 45 dB.

Further information about Rehau 70/80 PVC window

TABLES AND SECTIONS

DOCUMENT AND LINK

Project

Have a look at our Gallery of PVC window realizations. Ideas and possibilities for your projects.
Let yourself be inspired.

Learn more

Technical drawings

To enhance your knowledge about our range, Giemme provides product technical drawings, a tool to increase the opportunity for users and professionals to immediately check sizes and solutions adopted.

Download PDF

Brochure

Please download Product information Brochure to increase your knowledge and discover even more features.
Enjoy.

Download PDF

Finishes

Possibility to choose in our wide variety of colours and essences. In addition to the standard colours, we also offer a wide selection of special colours.

Learn more

Opening solutions

We offer a variety of opening for each single Giemme window system.
In addition to standard openings Giemme is always available to assess your needs.

Learn more
